Syntech PU Foam 30

Closed cell expanded polyurethane covering of 30 kg/m3

Syntech PU Foam 30 is an expanded polyurethane with a nominal density of 30 kg per m³; it is a closed cell foam, developed using a new generation blowing agent designed to adhere to various supports and capable of providing both excellent thermal insulation and minimizing air leaks. As part of a system, it has been designed as a closed cell, tested and evaluated for use as a composite system to provide a complete air barrier and to provide exceptional performance in reducing heat transfer, achieving incredible benefits such as minimizing the humidity transmission and air leaks. The performance of Syntech PU Foam 30 has been evaluated on iron, sheet metal, steel, glass, concrete and wood as a composite system or together as a single system.
Components
Two-components
Appearance
Liquid
Customs code
3909 5090

Request product info

    By submitting I agree to the privacy notice

    Lines of belonging
    Linea prodotto Building
    Features and benefits
    Where it is used
    How to use
    Technical data
    Warnings and precautions
    Media
    Related products

    Syntech PU Foam 30

    Syntech PU Foam 30 guarantees adhesion with excellent support, giving rise to a continuous membrane, without any joints and extremely resistant: - It adapts to any geometric shape - Friend of the environment, they are inert and disposable materials. - Does not weigh down the structure - Low permeability - Better thermal insulation - Reduced thicknesses compared to other insulators - Elimination of thermal bridges - Long life - useful life exceeding 50 years. - Excellent compressive strength - Resistant to biological attack and does not favor the growth of fungi and bacteria


    Fields of application

    Syntech PU Foam 30 expanded polyurethane is particularly used for: - Thermal insulation on buildings, attics, ceilings - Waterproofing following the use of top covering coating - Coating of foundations - Coating of cisterns and reservoirs - Coating of isothermal vans - Protection of pipelines and pipes - Cold room lining - Coating and protection of sheet metal.


    Allowed supports
    Concrete
    Prefabricated concrete
    Wood
    Metal surfaces
    Fiber-cement
    Glass
    Steel
    Preparation of supports

    All surfaces must be free of contaminants and humidity less than 3%; it must offer a mechanical grip on a solid and non-yielding support. Where necessary, we recommend preparation using shot peening, bush hammering, sanding or hydrowashing. Consult personnel for correct preparation of the support. It is recommended to use, if necessary, primers from the Syntech family and contact the staff for clarification on the most suitable type to use.


    Mode of use

    Syntech PU Foam 30 requires a bimixer system capable of producing pressure over 160 bar and temperatures over 60 °C, equipped with transfer pumps with a 3:1 ratio. Contact the staff for clarification on the best gun to use and details relating to the air system. The two components must be preheated to around 30 C° using heating bands. Syntech PU Foam 30 must be sprayed at pressures that fall within the range of 140 -160 bar and at temperatures that can vary from 35 to 45 °C. It is the applicator's responsibility to correctly calibrate the technical equipment taking into account the combination of nozzles relating to the gun, the length of the hoses and the technical parameters of the spray system. Syntech PU Foam 30 must not be applied in thicknesses greater than 3 cm per coat. The next step should not be carried out before 30 minutes have passed since the previous application, giving the material time to cool.


    Application methods
    Two-components hot sprayer
    Tool cleaning
    Thinner for resins
    Key features
    Density
    Density: 1.12 g/cm³
    Shelf-life
    Shelf-life: 12 months
    Temperature of use
    Temperature of use: +10/+30 °C
    Use wearing protective glasses
    Use wearing protective glasses
    Use wearing protective gloves
    Use wearing protective gloves
    Technical specifications

    Yield of a two-component kit

    13-15 m³

    Gel time
    EN 14315-1:2013

    12 s

    Permeability to water vapor
    EN 12086:2013

    30 μ

    Compressive strength
    EN 826

    CS(10/Y) da 150 kPa
    Resistant to chemical agents

    Capillary absorption
    EN 1609:2013

    0.18 kg/m²


    EN 14315-1:2013

    30 kg/m³

    Touch hardening at 20°C
    EN 14315-1:2013

    14 s

    Fire resistance
    EN 13501-1:2009

    CLASS E
    Consumption

    Approximately 0.350 kg of Syntech PU Foam 30 for each square meter of surface to be coated and for each centimeter of thickness to be created

    Available colors
    Neutral tending to yellow
    Packaging and dimensions
    Barrel 250 kg [A]
    Barrel 215 kg [B]
    Kit: 1 Barrel 250 kg [A] + 1 Barrel 215 kg [B]
    Storage and conservation
    Protect from freezing.
    Warnings
    The general information, along with any instructions and recommendations for use of this product, including in this data sheet and eventually provided verbally or in writing, correspond to the present state of our scientific and practical knowledge.
    Any technical and performance data reported is the result of laboratory tests conducted in a controlled environment and thus may be subject to modification in relation to the actual conditions of implementation.

    Azichem Srl does not assume any liability arising from inadequate characteristics related to improper use of the product or connected to defects arising from factors or elements unrelated to the quality of the product, including improper storage.
    Those wishing to utilise the product are required to determine prior to use whether or not the same is suitable for the intended use, assuming all consequent responsibility.

    The technical and characteristic details contained in this data sheet shall be updated periodically. For consultation in real time, please visit the website: www.azichem.com. The date of revision is indicated in the space to the side. The current edition cancels out and replaces any previous version.

    Please note that the user is required to read the latest Safety Data Sheet for this product, containing chemical-physical and toxicological data, risk phrases and other information regarding the safe transport, use and disposal of the product and its packaging. For consultation, please visit: www.azichem.com.
    It is forbidden to dispose of the product and/or packaging in the environment.
