Fields of application
Structural reinforcements of structural elements (beams, pillars, etc.) by bonding steel sheets to the concrete. Reconstruction of joints in concrete floorings. Rigid structural bonding (beton plaque) of prefabricated elements and of articles in different building materials: concrete, steel, glass, wood, marble, tiles, stones etc. Anchoring, bonding and attachment of connectors, ties etc. Attachment of elastic straps for waterproofing joints, Elastotex. Reconstruction of wooden heads, crack repair, reconstruction of missing geometries on various supports.
Allowed supports
Concrete
Prefabricated concrete
Wood
Floor screed
Rock walls
Steel
Preparation of supports
The application surfaces must be suitably prepared and adequately resistant: free from dust, grease, soiling, crumbling and non-adhering parts, devoid of wet surface areas. For floorings, moreover, a shot peening or preliminary milling of the surfaces of adhesion is recommended. The metal elements are to be blasted to "almost white metal".
Mode of use
Make sure that the environment is well ventilated and wear the personal protective equipment mentioned in the safety data sheet. Add component B to component A, taking care to remove all the material from the packaging and mixing thoroughly with a mixer at a low number of revolutions (or a suitable manual tool), until a homogeneous mixture is obtained, indicated by the uniform colour and the absence of lumps. Apply to the surfaces with the help of spatulas, trowels, etc. Complete the tasks during the useful life of the product.
Do not apply in rainy days; do not apply on moist or wet supports; do not apply on pulverised supports; use the product immediately after mixing.
Technical specifications
Flexural strength
DIN 53452 a 20ยฐC
31 ยฑ5% N/mmยฒ
Complete hardening at 20ยฐC
a 20ยฐC
7 day
Gel time
UN 8701-8 a 20ยฐC
60 ยฑ3.5% min
Static elastic modulus
EN 13412
4.1 GPa
Touch hardening at 20ยฐC
a 20ยฐC
2 h
Compressive strength
ASTM D 695
65 ยฑ5% N/mmยฒ
Breaking load longitudinal
ASTM D 638/2 a 20ยฐC
35 ยฑ5% N/mmยฒ
Dry residue
10โ a 150ยฐC
96 ยฑ1 %
Longitudinal elongation at break
ASTM D 638/2 a 20ยฐC
3 %
Consumption
Approximately 1.6 kg of Syntech AS 31 for each cubic decimetre of volume to be grouted.
Packaging and dimensions
Kit: 1 Can 5 kg [A] + 1 Can 2.5 kg [B]
Kit: 1 Canister 1 kg [A] + 1 Canister 0.5 kg [B]
Storage and conservation
Store the product in its original packing, in a fresh and dry environment, avoiding frost and direct sunlight.
Warnings
The general information, along with any instructions and recommendations for use of this product, including in this data sheet and eventually provided verbally or in writing, correspond to the present state of our scientific and practical knowledge.
Any technical and performance data reported is the result of laboratory tests conducted in a controlled environment and thus may be subject to modification in relation to the actual conditions of implementation.
Azichem Srl does not assume any liability arising from inadequate characteristics related to improper use of the product or connected to defects arising from factors or elements unrelated to the quality of the product, including improper storage.
Those wishing to utilise the product are required to determine prior to use whether or not the same is suitable for the intended use, assuming all consequent responsibility.
The technical and characteristic details contained in this data sheet shall be updated periodically. For consultation in real time, please visit the website: www.azichem.com. The date of revision is indicated in the space to the side. The current edition cancels out and replaces any previous version.
Please note that the user is required to read the latest Safety Data Sheet for this product, containing chemical-physical and toxicological data, risk phrases and other information regarding the safe transport, use and disposal of the product and its packaging. For consultation, please visit: www.azichem.com.
It is forbidden to dispose of the product and/or packaging in the environment.
