Epomalta LC

Epoxy mortar for the reconstruction of wooden structures

A castable epoxy mortar, comprised of a two-component epoxy adhesive (A + B) to be integrated with a mixture of select mineral aggregates with a maximum diameter of 4 mm. It is used for anchoring, restoring industrial flooring, the localised regeneration of wooden beam heads, repairs and building reconstructions in general, to be completed by pouring on-site, after creating dedicated containment formwork suitably waterproofed with a release agent.
Components
Three-components
Appearance
Liquid + Powder
Customs code
3907 3000

Request product info

    By submitting I agree to the privacy notice

    Obtained Certifications and Regulations
    EN 1504-3
    Lines of belonging
    Linea prodotto Infratech
    Linea prodotto Opus
    Where it is used
    How to use
    Technical data
    Additional content
    Warnings and precautions
    Media
    Related products
    Fields of application
    Anchoring with precision alignment of industrial machinery. Anchoring of metal elements. Localised restoration of industrial flooring subject to high static and dynamic loads. Reconstruction of joints in industrial flooring. Levelling of screeds and flooring. Localised regeneration of wooden beam heads. Reconstruction of construction artefacts in general.
    Allowed supports
    Concrete
    Wood
    Floor screed
    Steel
    Preparation of supports
    The surfaces on which it is to be applied are to be clean, dry, free from dust, dirt, and the like, as well as being adequately consistent. Be sure to remove any deteriorated parts of the surface.
    Mode of use
    Combine component B with component A, being sure to add all of the material contained in the packages then thoroughly mixing with a low-speed mixer until a perfectly homogeneous mixture is obtained. Add the required amount of โ€œchargerโ€ (component C), continuing to mix until reaching the original homogeneity of the adhesive system.
    As regards the anchoring of machinery, before positioning the machine, remove any deteriorated concrete and loose parts from the foundation surface, including any parts saturated with oil or grease. Check that air vent holes have been made on the base plate of the machine. During the first 10 hours following installation, ensure the substrate is not subject to vibrations from other machinery.
    Regarding the reconstruction of the wooden beam heads, apply in the manner dictated by the type of operation, subject to:
    - beam shoring
    - insertion of reinforcing bars
    - the construction of suitable formwork
    - applying (pouring) cement.
    Do not apply to wet and/or powdery media. Use the product immediately after mixing.

    Application methods
    Brick trowel
    Pour out
    Spatula
    Tool cleaning
    Thinner for resins
    Key features
    Density
    Density: 1.08 kg/dmยณ
    Maximum diameter of aggregate
    Maximum diameter of aggregate: 2.5 mm
    Pot-life
    Pot-life: 60 min
    Shelf-life
    Shelf-life: 12 months
    Solvent-free
    Solvent-free
    Temperature of use
    Temperature of use: +5 / +35 ยฐC
    Use wearing protective gloves
    Use wearing protective gloves
    UV-resistant
    UV-resistant
    Technical specifications

    Compressive strength after 28 days
    UNI EN 12190

    80 N/mmยฒ

    Chloride content
    UNI EN 1015-17

    0.01 %


    UNI EN 1544

    0.32 mm

    Touch hardening at 20ยฐC
    a 20ยฐC

    2 - 4 h

    Bonding force
    UNI EN 1542

    3.5 N/mmยฒ

    Static elastic modulus
    UNI EN 13412

    21000 N/mmยฒ

    Skid resistance
    UNI EN 13036-4

    CLASS I

    Capillary absorption
    UNI EN 13057

    0.01
    Consumption
    Approximately 1.55 kg of Epomalta LC is required for each cubic decimetre of volume to be reconstructed (about 1550 kg per cubic metre).
    Available colors
    Light gray
    Packaging and dimensions
    Can 1 kg [A]
    Can 0.5 kg [B]
    Pail 7.5 kg [C]
    Kit: 1 Can 1 kg [A] + 1 Can 0.5 kg [B] + 1 Pail 7.5 kg [C]
    Storage and conservation
    Protect from freezing.
    Additional content

    Warnings
    The general information, along with any instructions and recommendations for use of this product, including in this data sheet and eventually provided verbally or in writing, correspond to the present state of our scientific and practical knowledge.
    Any technical and performance data reported is the result of laboratory tests conducted in a controlled environment and thus may be subject to modification in relation to the actual conditions of implementation.

    Azichem Srl does not assume any liability arising from inadequate characteristics related to improper use of the product or connected to defects arising from factors or elements unrelated to the quality of the product, including improper storage.
    Those wishing to utilise the product are required to determine prior to use whether or not the same is suitable for the intended use, assuming all consequent responsibility.

    The technical and characteristic details contained in this data sheet shall be updated periodically. For consultation in real time, please visit the website: www.azichem.com. The date of revision is indicated in the space to the side. The current edition cancels out and replaces any previous version.

    Please note that the user is required to read the latest Safety Data Sheet for this product, containing chemical-physical and toxicological data, risk phrases and other information regarding the safe transport, use and disposal of the product and its packaging. For consultation, please visit: www.azichem.com.
    It is forbidden to dispose of the product and/or packaging in the environment.
