Syntech RGS

Epoxy adhesive for structural construction joints, brushable

A fluid, medium-viscous epoxy adhesive for the structural casting of joints (new conglomerates on existing structures). After careful mixing, the two-component compound must be applied on the existing concrete by brush or roller, a few minutes before applying the new conglomerate (โ€œwet-on-wetโ€).
Components
Two-components
Appearance
Liquid
Customs code
3907 3000

Request product info

    By submitting I agree to the privacy notice

    Obtained Certifications and Regulations
    EN 1504-6
    Lines of belonging
    Linea prodotto Building
    Linea prodotto Floor
    Linea prodotto Infratech
    Where it is used
    How to use
    Technical data
    Additional content
    Warnings and precautions
    Media
    Fields of application

    Construction joints between new and existing concrete, flooring and structures. Sealing and filling of cracks in the concrete (of a magnitude greater than 1 mm).


    Allowed supports
    Concrete
    Fiber-cement
    Tiles
    Floor screed
    Asphalt
    Rock walls
    Steel
    Preparation of supports

    The application surfaces should be suitably prepared and adequately resistant: free from dust, grease, fouling, crumbling and non-adhering parts, free of detected surface humidity, for floorings, moreover, it may be advisable to carry out preliminary shot peening or milling of adhesive surfaces.


    Mode of use

    Add component B to component A taking care to remove all the material from the packaging, mix thoroughly with a mixer at a low number of revolutions, until a perfectly homogeneous mixture is obtained; add the required load amount (component C) continue to mix until a homogeneous lump-free mixture is obtained. Apply by brush or roller on the surfaces prepared. Spread, or "cast" on site, the subsequent conglomerate, in the range of application defined by the conditions of adherence of Syntech RGS (before it hardens).


    Application methods
    Pour out
    Brush
    Paint roller
    Scrubbing brush
    Tool cleaning
    Syntech Diluente Epoxy
    Key features
    Density
    Density: 1.15 (ยฑ0.05) kg/dmยณ
    Pot-life
    Pot-life: 30 min
    Shelf-life
    Shelf-life: 12 months
    Solvent-free
    Solvent-free
    Temperature of use
    Temperature of use: +10 / +35 ยฐC
    Use wearing protective gloves
    Use wearing protective gloves
    Technical specifications

    Static elastic modulus

    โ‰ฅ 2000 N/mmยฒ

    Adherence to steel
    EN 12188

    โ‰ฅ 12 N/mmยฒ

    Dry residue
    10โ€™ a 150ยฐC

    68 %

    Compression shear strength at 70ยฐ
    EN 12188

    โ‰ฅ 70 N/mmยฒ

    Shear strength
    EN 12615

    โ‰ฅ 6 N/mmยฒ

    Glass transition temperature

    โ‰ฅ 40 ยฐC

    Viscosity
    UNI 8701/3

    16000 ยฑ3200 mPa

    Reaction to fire

    Class E

    Complete hardening at 20ยฐC
    a 20ยฐC

    7 day

    Compression shear strength at 50ยฐ
    EN 12188

    โ‰ฅ 50 N/mmยฒ

    Compressive strength

    โ‰ฅ 30 N/mmยฒ

    Free-phase withdrawal/expansion

    โ‰ค 0.1 %

    Touch hardening at 20ยฐC
    a 20ยฐC

    4-6 h

    Compression shear strength at 60ยฐ
    EN 12188

    โ‰ฅ 60 N/mmยฒ
    Consumption

    Apply from 0.30 to 1,00 kg of Syntech RGS per square metre of surface to be treated.

    Available colors
    Red
    Packaging and dimensions
    Can 3.3 kg [A]
    Can 1.7 kg [B]
    Kit: 1 Can 3.3 kg [A] + 1 Can 1.7 kg [B]
    Can 13.4 kg [A]
    Can 6.6 kg [B]
    Kit: 1 Can 13.4 kg [A] + 1 Can 6.6 kg [B]
    Storage and conservation
    Protect from freezing.
    Additional content

    Warnings

    Do not apply in the presence of stagnant water at the surface; do not make the new cast if the product lacks the necessary "stickiness". If, after its application, Syntech RGS should unfortunately harden before having placed the new conglomerate, it is recommended that you do not proceed, since the separation between the two bodies would be very likely! In these cases, it is recommended to apply a new layer of Syntech RGS, above the already hardened one, and proceed normally (as described above).

    The general information, along with any instructions and recommendations for use of this product, including in this data sheet and eventually provided verbally or in writing, correspond to the present state of our scientific and practical knowledge.
    Any technical and performance data reported is the result of laboratory tests conducted in a controlled environment and thus may be subject to modification in relation to the actual conditions of implementation.

    Azichem Srl does not assume any liability arising from inadequate characteristics related to improper use of the product or connected to defects arising from factors or elements unrelated to the quality of the product, including improper storage.
    Those wishing to utilise the product are required to determine prior to use whether or not the same is suitable for the intended use, assuming all consequent responsibility.

    The technical and characteristic details contained in this data sheet shall be updated periodically. For consultation in real time, please visit the website: www.azichem.com. The date of revision is indicated in the space to the side. The current edition cancels out and replaces any previous version.

    Please note that the user is required to read the latest Safety Data Sheet for this product, containing chemical-physical and toxicological data, risk phrases and other information regarding the safe transport, use and disposal of the product and its packaging. For consultation, please visit: www.azichem.com.
    It is forbidden to dispose of the product and/or packaging in the environment.
