SANAFLUENS
Superfluid grout based on reinforcing, injectable hydraulic lime mortar
Code: GRT.0154
Components: 1
Appearance: Powder
Powder preparation, ready-to-use, based on hydraulic lime, for the preparation, with the sole addition of water, of grout for masonry reinforcement, injectable and castable, high performance in terms of sliding, strength and stability, for ecological building interventions and the restoration of vintage buildings and monuments.
Customs Code
Linee di appartenenza
Certification obtained and Standards
EN 998-2
Masonry mortars - Masonry mortar for general purposes (G)
M20
EN 998-2
General characteristics
Dosage: 1.50 - 1.55 kg/dm³
Pot-life: 60 min
Shelf-life: 12 months
Mix with water: 22-24 %
Temperature of use: +6 / +30 °C
Technical specifications
Water penetration after capillary absorption
2.4 mm
Bonding force
1.2 N/mm²
Static elastic modulus
12000 MPa
Thermal conductivity
0.67 W/m*K
Permeability to water vapor
15/35 μ
Capillary absorption
0.53 kg•h^0.5/m²
Compressive strength
> 20 N/mm²
Density
1980 kg/m³
Chloride content
0.0082 %
Flexural strength
> 6 N/mm²
Available colours
- Gray
Packaging and dimensions
- Bag 25 kg
- Pallet: 50 x (Bag 25 kg)
Characteristics
In the SANAFLUENS mixtures, the water is completely and stably incorporated from the hydration reaction of lime; conversely, in traditional mixtures, a very high part of added water, is free, and evapourating, it leaves gaps in the walls.
SANAFLUENS is based on natural hydraulic lime, sodium gluconate, kaolin, aluminates; it does not contain cement, resins, solvents and radioemissive aggregates.
Consumption
Approximately 1500 kg of SANAFLUENS for each cubic metre of volume to be filled.
Use fields
Wall reinforcements of "bag" masonry or masonry damaged by earthquake by injections.
Preparation of supports
Clean the application surfaces by spraying abundantly with water. If there is a lack of plaster, apply a suitable render of hydraulic lime and sand (such as UNTERSANA) to close as much as possible the escape routes of the grout once it has been injected. Trace, from bottom to top and from left to right, a 50 cm square grid. On the intersection of the squares, drill the masonry with a rotary drill, with a bit of at least 22 mm in diameter, to a depth of at least 3/5 of its thickness, tilting the drill downwards by about 20 °. Once all the holes have been drilled, they will be sucked up, blown with compressed air and sprayed with water, to remove the dust inside them produced by the drilling. Insert in the holes for a depth of about 5 cm, transparent meshed rubber tubes, with a total length of at least 30 cm (therefore with about 25 cm external). Properly seal the perimeter of the pipe with ANCHORSANA FIX accelerated setting grouting mortar to prevent the injected product from escaping. Inject the grout always keeping it lightly mixed and operating a continuous flow, without interruptions.
Use method
Pour about 2/3 of the mixing water into the mixer. Gradually add SANAFLUENS and the water still required, continue to mix until a fluid, homogeneous, lump-free grout of the desired consistency is obtained. The mixing water indicatively necessary is equal to 22-24% by weight (5.5 - 6 litres per bag).
Reinforcing backfills and fills can be carried out both by gravity and using manual or automatic pumps, depending on the type of application. To verify the effectiveness of the reinforcement, the grout will come out of the pipes adjacent to that in which it is injected.
Application methods
- Injection
- Pour out
- Pump
Tool cleaning
- Water
Permitted supports
- Bricks
- Mixed walls (bricks and stones)
- Stone walls
Warnings, precautions and Ecology
An abundant preliminary injection of water into the holes drilled in the masonry is recommended, to allow an adequate and rapid sliding of the grout.
