REPAR TIX HG

Structural, thixotropic, fibre reinforced cement mortar

Code: REP.0136

Components: 1

Appearance: Powder

Thixotropic, structural, fibre reinforced cement mortar with high intrinsic watertightness, and extraordinary physical and mechanical characteristics: adhesion to concrete, adhesion to steel, compression resistance, flexural strength, abrasion resistance. Perfect for remediation of structural works and articles in degraded concrete and very high performance coatings. Thanks to the very high adhesion to steel and concrete supports, it is also suitable for fixing threaded bars in holes made on concrete or rock conglomerates. Apply with brick trowel and plastering trowel.

Customs Code

3824 5090

Linee di appartenenza

Certification obtained and Standards

EN 998-1

Specification for Mortar for Masonry - General purpose rendering/plastering mortar (GP)

EN 1504-3

Products and systems for the protection and repair of concrete structures - Structural and non-structural repair (R4)

General characteristics

Max. recommended thickness: 40 mm

Shelf-life: 12 months

Use wearing protective gloves

Temperature of use: +5 / +35 °C

Mix with water: 16 %

Highlighted product

Maximum diameter of aggregate: 1.5 mm

Min. recommended thickness: 7 mm

Pot-life: 30 min

Technical specifications

Density

2220 kg/m³

Skid resistance

61.0 mm

Chloride content

< 0.01 %

Contrasted expansion with air curing for 1 day

> 0.01 %

Water/binder ratio

< 0.37 _

Flexural strength after 28 days

> 9.0 N/mm²

Compressive strength after 07 days

50 N/mm²

Determination of thermal compatibility

≥ 2 N/mm²

Resistance to carbonatation

0.5 mm

Compressive strength after 90 days

≥ 70 N/mm²

> 12 _

Compressive strength after 28 days

≥ 65 N/mm²

Reaction to fire

A1 _

Bonding force

≥ 2 N/mm²

Capillary absorption

0.30 kg•h^0.5/m²

Flexural strength at 01 day

5 N/mm²

Static elastic modulus

26000 N/mm²

Compressive strength after 01 day

25 N/mm²

Available colours

- Gray

Packaging and dimensions

- Bag 25 kg

- Pallet: 50 x (Bag 25 kg)

Characteristics

Rheoplastic, thixotropic, structural, composite cement mortar, based on special cements and selected siliceous aggregates, reinforced with a balanced mixture of READYMESH polypropylene fibres and calcium metasilicate microfibres, added with specific agents and a high content of silica fume. After hardening, it provides very high performance in terms of intrinsic watertightness, resistance to washing and hydrolysing, mechanical strength, abrasion and cavitation, anti-carbonation, chemical-physical stability, resistance to harsh atmospheric agents and to leaching water. It is fibreglass reinforced three-dimensionally, it provides high adherence and adhesion; and dimensionally stable (shrinkage-compensated). The product is mixed with water (approx. 16% of the weight of the bag).

Consumption

Approximately 18,5 kg/m² of REPAR TIX HG for every centimetre of thickness to be implemented (approximately 1850 kg per cubic metre).

Use fields

Repairs and protective coatings of hydraulic works (pipelines, dams, tunnels etc.), marine structures and artefacts in critical situations: aggressive chemical-physical agents, leaching water, marine atmosphere, etc. For wet spritz beton operations it is advisable to use the REPAR TIX HG SB mortar, which maintains the physical and mechanical characteristics of REPAR TIX HG, but is specially formulated for the maximum performance of sprayer machines.

Preparation of supports

Application surfaces should be clean, free of soiling, crumbling and non-adhering parts, dust, etc., conveniently saturated with water until they reach the condition "saturated with dry surface". An adequate roughening of the surfaces by scarifying, sandblasting etc. is always necessary in order to obtain the maximum adhesion values to the substrate. The optimal values are obtained with high pressure hydro-scarification. Bare the irons undergoing disruptive oxidation or deeply oxidized, removing the rust of the exposed irons (by sandblasting or abrasive brushes).

Use method

Pour about 2/3 of the mixing water into the mixer, add REPAR TIX HG and the remaining water; continue to mix until a homogeneous lump-free mixture is obtained. The mixing water should be about 16% of the weight of the bag.

The addition of BOND HG to the mixing water (about 0.5 litres per 25 kg bag of product) allows further improvements in terms of adherence, adhesion, watertightness, workability, moldability and deformability.

For high coating thicknesses, static, monolithic requirements, etc., performed with REPAR TIX HG, appropriate metal reinforcements (mesh, cages, etc.) should be used, anchored to the support with SYNTECH PROFIX, GROUT MICROJ, REPAR TIX G2, or with the same REPAR TIX HG.

Application methods

- Brick trowel

- Finishing trowel

- Spatula

- Sprayer

Tool cleaning

- Water

Permitted supports

- Bricks

- Concrete

- Mixed walls (bricks and stones)

- Prefabricated concrete

- Rock walls

- Stone walls

Warnings, precautions and Ecology

Do not apply in case of direct exposure to sunlight or strong ventilation. Cure the protection and the prolonged moist hardening of surfaces laid.

Integrated solutions

Repair of concrete structures in marine environments

Volumetric reconstruction cycle and repair of works and structures in highly degraded concrete in aggressive environments such as marine, mountain and industrial environments.
