OSMOCEM iTOP

Osmotic plastic-deformable two-component waterproofing cement

Code: OSM.0349

Components: 2

Appearance: Powder + Liquid

An osmotic two-component cement compound for waterproofing with the addition of specific flexible polymers, it is plastic-deformable and resistant even with counterthrust to render impermeable concrete works, roofing, pools, cracked plaster, elevator compartments, balconies, terraces, and more. It can also be used for repairs and protective coating of hydraulic works and marine structures or in aquatic atmospheres.

Linee di appartenenza

Certification obtained and Standards

Products and systems for the protection and repair of concrete structures - Surface protection systems for concrete

EN 1504-2

Products and systems for the protection and repair of concrete structures - Surface protection systems for concrete

Regulation concerning materials and objects that can be used in fixed systems for the collection, treatment, adduction and distribution of water intended for human consumption (in implementation of Directive 98/83/CE).

D.M. 06/04/2004, n. 174

Regulation concerning materials and objects that can be used in fixed systems for the collection, treatment, adduction and distribution of water intended for human consumption (in implementation of Directive 98/83/CE).

General characteristics

highlighted-product

Highlighted product

maximum-diameter-of-aggregate

Maximum diameter of aggregate: < 0.4 mm

min-recommended-thickness

Min. recommended thickness: 1.5 mm

pot-life

Pot-life: 50-70 min

shelf-life

Shelf-life: 12 months

temperature-of-use

Temperature of use: +5 / +35 °C

to-be-applied-in-two-coats

To be applied in two coats

Technical specifications

2.2 N/mm²

Capillary absorption

0.027 kg•h^0.5/m²

Coefficient of permeability

< 5 mm

Compressive strength after 28 days

> 9.0 N/mm²

Compressive strength at 02 days

2.5 N/mm²

Density

1600 g/l

Exposure to artificial weathering-2000 hours

no swelling. no cracking. no flakin _

Flexural strength after 28 days

> 3.0 N/mm²

Flexural strength at 2 days

> 1.0 N/mm²

Longitudinal elongation at break

15 %

Mixing ratio of the components

3.12:1 _

Permeability to CO2

Sd 93 m

Permeability to water vapor

Sd 0.9866 _

Thermal compatibility after cooling shocks - storm cycles

1.8 N/mm²

Available colours

- Gray

- White

Packaging and dimensions

- Bag 25 kg [A]

- Plastic can 8 kg [B]

- Kit: 1 Bag 25 kg [A] + 1 Plastic can 8 kg [B]

Characteristics

OSMOCEM iTOP is characterised by an extreme ease of application, being veritably fool-proof. It permits adherence to supports for mechanical adhesion and osmotic diffusion. It is also effective in conditions of negative hydrostatic thrust (counterthrust) and is applicable as a coating in rooftop gardens and planters due to its resistance to the mechanical action of roots.

Consumption

Approximately 1.6 kg/m² of OSMOCEM iTOP for each millimetre of thickness to be made.

Use fields

Waterproofing treatments for underground structures and masonry, swimming pools, tubs, planters, rooftop gardens, ducts, tunnels, pits, bridges, tanks, basements, food containment areas and so on whereby sufficiently porous and absorbent, being free from any water-resistant and/or water-repellent surface treatment, be it chemical (siloxanes, epoxy, polyurethane, etcetera) or natural (waxing). Suitable for both positive and negative hydrostatic thrust conditions, it can also be used for waterproofing terraces and balconies.

Preparation of supports

The applicative surfaces must be clean, free from contamination or any loose or detached parts, dust, water-repellent treatments in general, and so on, being suitably watered down until it is “saturated with a dry surface”.

Use method

Mix the powder (component A) with the hydrating solution (component B) using a drill at low-speed or other effective mechanical mixer, gradually adding the powder to the liquid. Continue mixing until reaching a homogeneous and lump-free mixture.
After mixing, wait a few minutes then stir again before applying.
To further improve the effects of the coating (for example, when waterproofing terraces and balconies), it is advisable to add the ARMAGLASS 160 alkaline-resistant fibreglass reinforcing mesh between one layer and the next, for a consumption of around 3-4 kg/m2 as a guideline.
Do not apply in the presence of direct insolation or when dealing with wet curing and protection.
Do not apply to substrates with little to no porosity or those previously coated with water-repellent treatments generally, except whereby following proper roughening by means of bush hammering machines, sanders or equipment suitable for preparatory surface treatment or specific treatment with suitable polymer primers.

Application methods

- Finishing trowel

- Plastering machine

- Brush

- Paint roller

- Spatula

- Sprayer

Tool cleaning

- Water

Permitted supports

- Plasters

- Concrete

- Prefabricated concrete

- Fiber-cement

- Bricks

- Mixed walls (bricks and stones)

- Stone walls

- Floor screed

- Rock walls
