GROUT 6 HP
Castable, rheoplastic and structural concrete with very high strength
Code: GRT.0264
Components: 1
Appearance: Powder
GROUT 6 HP is a high-performance castable mortar, equipped with mechanical compressive and bending resistance far superior to normal structural mortars. It is used for repairs, replenishments, strengthening concrete reinforcement and special works in HPC. The special additives contained in the formulation are able to compensate for shrinkage and the development of exceptional rheological characteristics.
Range
Customs Code
Linee di appartenenza
Certification obtained and Standards
EN 1504-6
Products and systems for the protection and repair of concrete structures - Anchoring of reinforcing steel bar
EN 1504-3
Products and systems for the protection and repair of concrete structures - Structural and non-structural repair (R4)
General characteristics
Mix with water: 10 %
Maximum diameter of aggregate: 6 mm
Min. recommended thickness: 2.5 cm
Pot-life: 10 min
Max. recommended thickness: 20 cm
Shelf-life: 12 months
Temperature of use: +5 / +35 °C
Technical specifications
Compressive strength after 01 day
50 N/mm²
Compressive strength after 07 days
80 N/mm²
Bonding force
3 N/mm²
Capillary absorption
< 0.5 kg•h^0.5/m²
Flexural strength after 28 days
12 N/mm²
Compressive strength after 28 days
100 N/mm²
Reaction to fire
A1 _
Chloride content
< 0.01 %
Flexural strength at 01 day
8 N/mm²
Flexural strength after 07 days
11 N/mm²
Density
2350 kg/m³
Resistance to carbonatation
0.5 mm
Static elastic modulus
32000 N/mm²
Available colours
- Gray
Packaging and dimensions
- Bag 25 kg
- Pallet: 50 x (Bag 25 kg)
Characteristics
With very low water-binder ratios, GROUT 6 HP makes it possible to achieve compacting and hyperfluid rheologies that favour the movement of the mortar and the perfect filling of reinforced sprays, even with narrow spaces between the bars. The microsilica with pozzolanic activity increases the cohesion of the mixture with typical anti-segregating and anti-run-off effect. The particular fineness of the hydraulic binders contained in the formula promotes adherence to the substrate and the rapid development of very high mechanical resistance, even just 24 hours from casting. With regard to the ANTICORROSIVE and PROTECTIVE FUNCTION ON THE REINFORCEMENT BARS, the main features of GROUT 6 HP SFR are:
• the mix of high-strength superfine binders, combined with very fine silicas with pozzolanic activities, to render the mortars intrinsically impermeable to water at the end of the hardening process;
• The strongly alkaline pH (> 12) protects the reinforcement bars from triggering corrosion;
• The negligible breathability of the carbon dioxide ensures hardened mortars with extremely prevalent anti-carbonation characteristics.
Overall, these anticorrosive specificities render the classic treatment of reinforcing bar passivation, preparatory to the pouring of castable mortar UNNECESSARY, provided that not too much time passes between the white metal cleaning operations and the castings of pourable mortar, at the risk of new oxidative processes being triggered. Thus, only in the event that long exposure times are foreseen between the bar-cleaning operations and the pouring of castable mortar is it advisable to treat with passivating slurry (REPAR MONOSTEEL or REPAR STEEL), applied by brush and only on the reinforcing bars.
Consumption
Approximately 20,5 kilograms/square metre of GROUT 6 HP per centimetre of thickness to be realised (about 2050 kilograms per cubic metre).
Use fields
On-site castings or pumping carried out for any kind of structural replenishment of reinforced concrete, seismic reinforcement and adjustment, increases in cross-sectional resistance of concrete structures and masonry, anchorages of large-scale machinery, anchoring of port bollards, deep-drawing and reinforcement works, restoration of highly-stressed industrial flooring both from a static and dynamic perspective, restoration of degraded foundations on bridges and viaducts especially whereby necessitating rapid reopening to vehicle traffic, construction of structures designed with HPC (High Performance Concrete) needs.
Preparation of supports
Application surfaces must be clean, free of dust, contamination, crumbling, inconsistencies, etc., and adequately saturated-surface-dry with water. An adequate roughening of the surfaces by scarifying, sandblasting etc. is always necessary in order to obtain the maximum adhesion values to the substrate. The optimal values are obtained with high pressure hydro-scarification. Bare the irons undergoing disruptive oxidation or deeply oxidized, removing the rust of the exposed irons (by sandblasting or abrasive brushes).
Use method
Mix the entire content of a bag of GROUT 6 HP with effective vertical-axis mixers for at least 6 minutes, initially introducing a slightly reduced amount of water (9% = 2.25 litres/25 kilograms bag) compared to the required total water permitted (10%–12% = 2.5 litres–3.0 litres/25-kilogram bag) whilst mixing for at least 4 minutes. After this mixing time, evaluate the consistency of the mixture and, if necessary, gradually add in the last of the water until achieving the desired workability, without exceeding the limit of 12% (3.0 litres/25-kilogram bag), mixing at high RPM for at least another two minutes. For thick casting sections, it is advisable to add GHIAIETTO 6.10 (consult the relevant technical data sheet or ask for more information on the appropriate dosage of GHIAIETTO 6.10 from our technical service). Given the self-levelling properties of the product and its self-compacting capacity, paying due attention to the vibration phase is recommended. Excessive zeal in the vibration operation can worsen the aesthetic rendering of the end result. Do not use in the absence of suitable lateral containment. Ensure exposed surfaces are protected and wet-cured. Adopt casting procedures to ensure the absence of voids and discontinuities. Only pour the mortar from one part of the casting perimeter to avoid air pockets.
Application methods
- Pour out
Tool cleaning
- Water
Permitted supports
- Brickworks
- Concrete
- Mixed walls (bricks and stones)
- Rusty reinforcement rods
- Stone walls
