GHIAIETTO 6.10

Dried fine gravel to be added to castable anti-shrinkage mortar

Code: ADX.0066

Components: 1

Appearance: Gravel

Dried, selected fine gravel, with particle size between 6 and 10 mm, specific for addition to premixed structural mortars and plasters, both castable and thixotropic, to improve or correct the particle size curve, based on the required increase in casting thickness.

Certification obtained and Standards

Product of the Sanageb line, the line of products from Azichem Srl dedicated to green-building, ecological sanitation, thermal insulation and energy saving products since 1994.

Sanageb - Prodotti naturali per la Bioedilizia

Product of the Sanageb line, the line of products from Azichem Srl dedicated to green-building, ecological sanitation, thermal insulation and energy saving products since 1994.

Product of the Floor line, the line of products from Azichem Srl dedicated to the main, complementary products and accessories for the construction, restoration and/or renovation of concrete floors and screeds.

Floor - Prodotti per pavimenti e massetti in calcestruzzo

Product of the Floor line, the line of products from Azichem Srl dedicated to the main, complementary products and accessories for the construction, restoration and/or renovation of concrete floors and screeds.

General characteristics

solvent-free

Solvent-free

uv-resistant

UV-resistant

nonflammable

Nonflammable

unlimited-shelf-life

Unlimited shelf-life

material-100-eco-friendly

Material 100% eco-friendly

consumption-by-weight-of-components

Consumption (% by weight of components): 20-40 %

maximum-diameter-of-aggregate

Maximum diameter of aggregate: 10 mm

Technical specifications

Density

1550 kg/m³

Available colours

- Light gray

Packaging and dimensions

- Bag 25 kg

- Pallet: 63 x (Bag 25 kg)

Consumption

Variable according to the different design requirements for dilution of structural castable mortars (see details in the technical data sheets of the GROUT line products).

Use fields

Addition to conglomerates based on mineral and polymeric hydraulic binders; size adaptation of premixed mortars and grouts.

Use method

Add the desired amount of fine gravel to the mixture, during the mixing of the same. Add any additional remaining water and product base, until a cohesive and lump-free mixture is obtained. Leave the mixed conglomerate to rest, with added gravel for a few minutes before laying it.

The dosage of GHIAIETTO 6.10, relative to the weight of the mixture of a product with water, can be maximum 30%-35% (100 kg of finished mixture with 30 kg of fine gravel).

PLEASE NOTE: to calculate the material required as a function of the volume to be filled, after having determined the required quantity of the preselected product based on the specific weight of the same (normally for a structural cement mortar it is about 1900 kg/m³), replace maximum 25% of the calculated weight with GHIAIETTO 6.10 . To facilitate the calculation, as a general rule consider using one bag of GHIAIETTO 6.10 for every three bags of (premixed) base product.

Application methods

- To be added to other components

Permitted supports

- Concrete

- Cement-based or lime-based mortars

Warnings, precautions and Ecology

Excessive dosage of GHIAIETTO 6.10 could result in reductions even significant in the stated mechanical performance for the product it is added to. Always follow the maximum dosages specified.

For more information, please consult our Technical Service.
